T Handle Female X Female 1 Inch Brass Gate Valve
Product Details:
| Place of Origin: | China |
| Brand Name: | DOUBLE-LIN |
| Certification: | ACS |
| Model Number: | LL4093 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 0 |
|---|---|
| Price: | 0 |
| Packaging Details: | Double-Lin standard packing |
| Delivery Time: | within 7 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50000 pcs |
|
Detail Information |
|||
| Item: | Brass Stop Valve | Size: | 1/2" - 1" |
|---|---|---|---|
| Brass Material: | HPb 57-3 | Connection Type: | Female X Female |
| Handle Material: | Brass Handle | Filler Material: | PTFE |
| Working Pressure: | 16 Bar(232 Psi) | Thread: | ISO228 (equivalent To DIN 259 And BS2779) |
| Working Temperature: | From -10 ℃ To +120 ℃ (from 14℉ To 248℉) | ||
| High Light: | HPb 57-3 1" brass gate valve,DIN 259 1 inch brass gate valve,HPb 57-3 1 inch brass gate valve |
||
Product Description
1/2 " To 1 " 16 Bar Brass Stope Valve With T Handle
- Description
Working Pressure 16bar (232 psi)
Working Temperature from -10 ℃ to +120 ℃ (from 14℉ to 248℉)
Thread ISO228 (equivalent to DIN 259 and BS2779)
- Details
Brass Valve Body: High-density forging, no blister, no air holes, no leakage. Made by special high precision CNC machines.
Brass Bonnet: Made of brass material in good quality to ensure wall thickness and is quite durable.
Brass Valve Spool: Adapt soft seal, PTFE seat with good sealing performance, can be suitable for different environments.
Filler: Made of PTFE in good quality, with excellent sealing performance to prevent leakage.
Hexagaonal Nut: Made of brass material in good quality, with strong tensile strength, good toughness and without deformation and cracking after long-time use.
Handle: Made of brass material in good quality. Novel apperance and confortable using feeling.
- Materials of Parts
| No. | Part | Materials |
| 1 | Body | Brass |
| 2 | Filler | PTFE |
| 3 | Bonnet | Brass |
| 4 | Lock Cap | Brass |
| 5 | Spool | Brass |
| 6 | Handle | Brass |
- Certificates of LL4093
- Company Profiles
Double-Lin, which was established in 2000 in China, is a manufacturing company for global market. Double-Lin products with self-owned brand are widely distributed to more than 100 countries and regions, and Chinese domestic market. Chairman Mr. Lin Hailin adopts strategic adjustment of industrial layout, the business scope is integrated into a comprehensive solution provider, including four major areas such as public buildings and household water control system, public buildings and home heating system, transportation and use of gas safety system, family bathroom hardware solutions, covering nearly 10,000 kinds of products and specifications.
- Our Package Details
1. Double-Lin logo forged in valve body.
2. Double-Lin logo stamped or printed on nameplate.
3. Inner box material is a 3-layer corrugated bond paper, with clear & attractive printing.
4. Product guarantee certificate.
5. PE plastic ECO bag.
6. Product spec. label sticked on the side of master carton.
7. Double-Lin special packing tape.
8. Master carton material is a 5-layer corrugated bond paper, with clear & attractive printing.
9. 2pcs of non-woven bags inside.
10. 1 copy of instruction manual inside.
- FAQ
Q: How long is your product guarantee period?
A: We have three-year guarantee and 24 hours full-time service.
Q: What is your MOQ?
A: We have no MOQ. We have a large warehouse and we promise "Instant Order, Immediate Delivery and No MOQ".
Q: Can you accept OEM?
A: Double-Lin is a company with self-owned brand, and we are promoting our brand in the world, so we will not accpet OEM.
Q: How long is your delivery time?
A: For the items if we have enough stocks, we can send to you immediately. For mass production, we can promise 30-35 days.
